Steel Construction Tile Roll Forming Machine with 1 Inch Transmission Chain and 75mm Roller Diameter for Roofing Panel Manufacturing

Product Description:

The Tile Roll Forming Machine is a high-performance industrial solution designed for the efficient manufacturing of tile sheets. Engineered with precision and durability in mind, this tile forming machine offers exceptional reliability and consistency, making it an ideal choice for businesses involved in the production of roofing and decorative tiles. Its robust construction and advanced control system ensure smooth operations and superior output quality, meeting the diverse needs of the tile manufacturing industry.

At the heart of this tile sheet forming machine lies a sophisticated PLC control system. The programmable logic controller (PLC) enables automated and accurate control of the entire production process, from feeding the steel material to the final forming and cutting stages. This automation reduces human error, enhances production efficiency, and allows operators to easily adjust operational parameters to suit different tile designs and specifications. The user-friendly interface of the PLC control system facilitates seamless monitoring and control, ensuring that the tile forming machine operates at optimal performance levels at all times.

Constructed primarily from high-quality steel, the tile roll forming machine boasts excellent structural integrity and durability. Steel is chosen for its strength, resistance to wear and tear, and ability to withstand the demanding conditions of continuous manufacturing. This robust material foundation ensures the machine’s longevity and stable operation, even under heavy workloads. The steel construction also contributes to the machine’s ability to produce consistently precise tile sheets, maintaining uniformity in shape and size throughout the production run.

One of the critical components of this tile sheet forming machine is its cutting blade, crafted from Cr12 steel. Cr12 is a high-carbon, high-chromium alloy known for its outstanding hardness, wear resistance, and toughness. These properties make the Cr12 cutting blade highly effective at cleanly cutting steel tile sheets without deforming or damaging the material. The sharpness and durability of the Cr12 blade reduce downtime caused by blade replacement or maintenance, thereby increasing overall productivity and ensuring a smooth, efficient cutting process.

In terms of size, the tile roll forming machine measures 6 meters in length, 1.5 meters in width, and 1.5 meters in height. This compact footprint allows for easy integration into existing production lines without requiring excessive floor space. Despite its relatively modest dimensions, the machine is designed to handle significant workloads and produce large volumes of tile sheets with consistent quality. Its size also facilitates straightforward installation and maintenance, making it a practical choice for manufacturers of various scales.

The transmission system of the tile forming machine employs a 1-inch transmission chain, which plays a vital role in the smooth and reliable transfer of mechanical power throughout the machine. The 1-inch chain is engineered for durability and strength, capable of withstanding the stresses of continuous operation while maintaining precise synchronization of the forming rollers and cutting mechanisms. This ensures that each tile sheet is formed and cut accurately according to the specified dimensions, minimizing waste and enhancing overall production efficiency.

Overall, this tile roll forming machine represents a perfect combination of advanced technology, durable materials, and thoughtful design. Whether you are looking to expand your tile manufacturing capacity or improve the quality and efficiency of your current production line, this tile sheet forming machine delivers outstanding performance and value. Its PLC control system, steel construction, Cr12 cutting blade, compact size, and reliable transmission chain collectively contribute to a robust and efficient solution for producing high-quality tile sheets consistently.

Choose this tile forming machine to benefit from streamlined production processes, reduced operational costs, and enhanced product quality. It is an excellent investment for manufacturers seeking to stay competitive in the fast-evolving tile industry by leveraging modern roll forming technology tailored specifically for tile sheet production.

Features:

• Product Name: Tile Roll Forming Machine
• Type: Tile Roll Forming Machine
• Material: Steel for durability and strength
• Control System: Advanced PLC control system for precise operation
• Weight: 8.5T ensuring stable performance
• Roller Stations: 18-30 stations for versatile tile sheet forming
• High efficiency tile sheet forming machine suitable for various tile profiles
• Reliable tile sheet forming machine designed for continuous production
• Robust Tile forming machine engineered to produce high-quality tile sheets

Technical Parameters:

Applications:

The Bluesteel Tile Roll Forming Machine, model BL-4, is a highly efficient and reliable tile sheet forming machine designed to meet diverse industrial needs. Originating from China, this electric-powered tile forming machine is equipped with an advanced PLC control system, ensuring precision and ease of operation. With productivity ranging from 5 to 30 meters per minute and a robust weight of 8.5 tons, the BL-4 model is built for heavy-duty performance and continuous production cycles. Its configuration includes 18 to 30 roller stations, which contribute to the consistent quality and durability of the formed tile sheets.

This tile roll forming machine is ideally suited for various application occasions, including construction material manufacturing plants, metal roofing factories, and building renovation projects. Its ability to produce uniform and high-quality tile sheets makes it indispensable in environments where speed and accuracy are essential. Whether the requirement is for residential roofing tiles, commercial building facades, or industrial roofing solutions, the Bluesteel BL-4 tile forming machine delivers superior results that meet stringent industry standards.

In addition to factory settings, the tile forming machine is also applicable in custom fabrication workshops where specialized tile sheet profiles are needed. The PLC control system allows operators to easily adjust parameters and customize production runs, making it versatile for different tile designs and thicknesses. This flexibility is particularly beneficial in scenarios where architectural aesthetics and functional performance must be balanced, such as in eco-friendly building projects and heritage restoration works.

The electric power source of the Bluesteel BL-4 tile sheet forming machine ensures energy efficiency and stable operation, reducing downtime and maintenance costs. Its sturdy construction, combined with the 18-30 roller stations, guarantees long service life and consistent output quality, making it a smart investment for businesses aiming to enhance productivity and product quality.

Overall, the Bluesteel BL-4 tile forming machine is a top-tier solution for manufacturers seeking a reliable, efficient, and adaptable tile roll forming machine. Its advanced features and robust design make it suitable for a wide range of occasions and scenarios in the construction and metal forming industries, driving forward innovation and excellence in tile sheet production.

Customization:

Our Bluesteel BL-4 Tile Roll Forming Machine offers extensive product customization services to meet your specific needs. As a high-quality steel tile forming machine made in China, the BL-4 model features adjustable roller stations ranging from 18 to 30, allowing you to customize the tile profiles and designs according to your project requirements.

The machine is equipped with 75mm diameter rollers, ensuring precision and durability during the tile forming process. With a productivity range of 5-30 meters per minute, the tile forming machine can be tailored for various production speeds based on your operational demands.

Additionally, the BL-4 Tile Roll Forming Machine includes a hydraulic cutting system fitted with Cr12 cutting blades. This system can be customized for different tile lengths and cutting specifications to optimize efficiency and accuracy. Whether you require specific tile dimensions or unique steel tile forming profiles, our customization services will adapt the machine to your exact needs.

Choose the Bluesteel BL-4 for a reliable and customizable tile forming machine solution that enhances your manufacturing capabilities and delivers consistent, high-quality steel tiles.

Packing and Shipping:

The Tile Roll Forming Machine is carefully packaged to ensure safe delivery and optimal condition upon arrival. Each machine is securely wrapped with protective materials such as foam and plastic covers to prevent any damage during transit. The components are tightly fastened and cushioned within a sturdy wooden crate or reinforced steel frame to withstand handling and shipping stresses.

For shipping, we offer multiple options including sea freight, air freight, and land transportation, depending on the destination and customer requirements. The packaging is designed to meet international shipping standards, ensuring the machine's integrity throughout the journey. All necessary documentation, including user manuals, warranty cards, and installation guides, are included inside the package.

Before dispatch, the Tile Roll Forming Machine undergoes thorough inspection and testing to guarantee it meets quality standards. We also provide clear labeling on the packaging for easy identification and handling instructions to facilitate smooth delivery and installation at the customer's site.
